Precision Cutting for Various Applications:
Achieve precise cutting results for a wide range of applications, including the construction of wooden post and beam structures, substructures for drywall construction, laying laminate/parquet flooring, wood panelling, and cover strips.
Efficient Brushless Motor:
Experience superior efficiency and durability with our brushless motor, ensuring reliable power and an extended service life for your cutting tasks.
Advanced Electronic Management System (EMS):
Our innovative EMS safeguards the machine, prolonging its service life and enhancing overall efficiency, ensuring optimal performance for every project.
Swift Motor Brake:
The motor brake stops the saw blade in just 3 seconds, ensuring enhanced safety and efficiency during operation.
Precise Marking with Laser Guide:
Mark your cutting line with precision using the integrated laser guide, positioned to the left of the saw blade for accurate alignment.
User-Friendly Angular Scale:
Benefit from the laser-cut angular scale, featuring preadjustments and easy-to-read markings for precise angle adjustments.
Versatile Swivel Segment:
The swivel segment offers a wide range of angles, with angle stoppers for undercuts, angular cuts, and schifter cuts, providing versatility for various cutting needs.
Rugged and Long-lasting Construction:
Built to withstand heavy-duty use, our saw is rugged and long-lasting, ensuring reliable performance in demanding environments.
Enhanced Workplace Cleanliness:
Keep your workspace clean with the Ø 36 mm vacuum flange, providing efficient dust extraction for a clearer view of the cut.
Sturdy Guide and Secure Workpiece Fixing:
Our saw features a robust double multi-direction guide and a quick-action clamping holder for secure fixing of the workpiece on the saw table, ensuring stability and accuracy during operation.
Ergonomic Design for Comfort:
Enjoy ergonomic handling with the comfortable handle, equipped with a switch lock for both left-handed and right-handed users, enhancing user comfort and control.
Battery Status Monitoring:
Stay informed about battery levels with the LED battery capacity display, allowing you to plan your work effectively and avoid interruptions.
Compatibility with FLEX Battery System:
Our saw is compatible with all FLEX 18.0 V battery packs, offering versatility and convenience for your power tool collection.
Technical Specifications:
Battery voltage | 18.0 V |
---|---|
Battery capacity | 2.5 / 5.0 / 8.0 Ah |
No-load speed | 5500 rpm |
Mitre setting, left | 48 ° |
Mitre setting, right | 48 ° |
Inclination setting, left | 48 ° |
Inclination setting, right | 48 ° |
Cutting depth, cross-cut mode 90°/90° | 66 mm |
Cutting depth, cross-cut mode 90°/45° right | 23 mm |
Cutting depth, cross-cut mode 90°/45° left | 35 mm |
Cutting depth, cross-cut mode 45°/90° | 66 mm |
Cutting depth, cross-cut mode 45°/45° right | 16 mm |
Cutting width, cross-cut mode 90°/90° | 245 mm |
Cutting width, cross-cut mode 90°/45° | 245 mm |
Cutting width, cross-cut mode 45°/90° | 155 mm |
Cutting width, cross-cut mode 45°/45° | 175 mm |
Cutting depth, cross-cut mode 45°/45° left | 35 mm |
Saw blade diameter | 190 mm |
Saw blade hole | 30 mm |
Dimensions WxLxH | 720 x 575 x 400 mm |
Weight without battery pack | 12.9 kg |
