Advanced Electronic Management System (EMS):
Benefit from enhanced machine protection, extended service life, and improved efficiency with our state-of-the-art EMS.
Next-Generation Brushless Motors:
Experience unparalleled efficiency and performance with our latest brushless motors, setting a new standard in power tools.
Effortless Operation:
Enjoy automatic start-up and built-in overload protection for seamless usage.
Variable Cutting Speed Control:
Achieve precision with ease using the continuously variable cutting speed setting via the intuitive potentiometer wheel, complete with automatic start-up in position "A".
User-Friendly Design:
Convenience is key with an electronic switch operable from both sides, ensuring ergonomic usage for all users.
Enhanced Cutting Options:
Choose from four orbital stroke settings to maximize cutting rates and efficiency.
Tool-Free Blade Change:
Streamline your workflow with our tool-free saw blade change system featuring a quick-clamping mechanism and eject function.
Precision Cutting:
Experience precise cuts with accurate angles thanks to the double roller jigsaw blade guide.
Optimized Performance:
Maximize tear-free cuts and guide the saw blade effectively with the removable chip screen.
Versatile Bevel Cuts:
Adjust the saw bench for bevel cuts of up to 45° with a secure 0-lock mechanism, allowing for precise cutting near edges.
Surface Protection:
Ensure delicate surfaces remain intact with the stable base plate featuring a removable plastic guide block.
Cleaner Workplace:
Keep your workspace tidy and maintain a clear view of your cuts with the integrated vacuum flange, Ø 27 mm.
Enhanced Visibility:
Enjoy unobstructed marking with the integrated blow function providing a clear view of your workpiece.
Comfortable Handling:
Experience optimal ergonomics with strategically placed SoftGrip surfaces for a comfortable grip during operation.
Illuminated Workspace:
Illuminate your work area with the integrated LED lamp, ensuring optimum visibility even in low-light conditions.
Smooth Operation:
Reduce fatigue and discomfort with low-vibration sawing for a more comfortable user experience.
Battery Status Monitoring:
Stay informed with the LED battery capacity display, allowing you to monitor power levels with ease.
Technical Specifications:
Battery voltage | 18,0 V |
---|---|
Battery capacity | 2,5 / 5,0 / 8,0 Ah |
Orbit rate, no load | 0 - 3500 rpm |
Stroke | 26 mm |
Pendulum stroke stages | 4 Steps |
Speed settings | 1-5 +A Steps |
Pivoting range | 0-45 ° |
Max. material thickness, wood | 120 mm |
Max. material thickness, metal | 8 mm |
Dimensions WxLxH | 240 x 77 x 220 mm |
Weight without battery pack | 2,1 kg |
