Cutting-Edge Electronic Management System (EMS):
Our Electronic Management System (EMS) provides comprehensive protection for the machine, extending its service life while enhancing efficiency for optimized performance.
Efficient Brushless Motor:
Experience superior efficiency and durability with our brushless motor, ensuring reliable power and extended longevity for your sawing tasks.
Advanced 18.0 V EC Motor:
Equipped with overload protection and temperature monitoring, our 18.0 V EC motor ensures safe and consistent operation, even in demanding conditions.
Convenient LED Battery Capacity Display:
Stay informed about battery levels with our LED battery capacity display, allowing you to plan your work effectively and avoid interruptions.
Dual Clamped Swivel Element:
Prevent saw blade jamming and minimize the risk of recoil during mitre cuts with our dual clamped swivel element, ensuring smooth and precise operation.
Quick Blade Replacement:
Our spindle lock enables quick and hassle-free replacement of blades, saving you time and effort during blade changes.
Versatile Angle Adjustment:
Easily adjust cutting angles from 0° to 50° with preset angles of 22.5°, 45°, and 50°, thanks to our intuitive angle scale and non-slip clamping elements.
Swivel Range and Scoring Function:
Achieve perfect visible edges with our swivel range from 0° to 50°, ideal for undercuts, and utilize the scoring function for precise cuts.
Intuitive Cutting Depth Adjustment:
Adjust cutting depth effortlessly with our intuitive clamp lever, providing easy-to-read cutting depth settings for accurate results.
Compliance with Latest Regulations:
Our saw is designed in accordance with the latest regulations, eliminating the need for a splitting wedge for plunge cuts and streamlining the removal process.
Low-Dust Operation:
Enjoy cleaner work environments with our woodshaving collection bag, which attaches tool-free for easy emptying and low-dust operation.
External Dust Extraction Compatibility:
Connect to external dust extraction systems with our Ø 27 mm connector or step adapter, ensuring efficient dust removal for cleaner and safer working conditions.
Versatile Applications:
Ideal for traditional applications in dry construction and refurbishing projects, our saw is perfect for making precise cuts through various materials, including plasterboard, concrete fiberboards, and wood materials like chipboard or OSB boards.
Technical Specifications:
Battery voltage | 18.0 V |
---|---|
Battery capacity | 2.5 / 5.0 / 8.0 Ah |
Cutting depth | 0-62 mm |
Cutting depth, mitre cut (45°) | 0-38 mm |
Saw blade diameter | 165 mm |
Saw blade hole | 20 mm |
Pivoting range | 0-50 ° |
Angle preset | 0 / 22,5 / 45 / 50 ° |
Dimensions WxLxH | 380 x 150 x 200 mm |
Weight without battery pack | 3.1 kg |
